Description
Aruba JL703C CX 8360-16Y2C V2 16 Ports Managed Rack Mountable Switch
| Product Description | HPE Aruba CX 8360-16Y2C V2 – switch – 16 ports – managed – rack-mountable |
| Device Type | Switch – 16 ports – L3 – managed |
| Enclosure Type | Back to front airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 16 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 2 x 40/100 Gigabit QSFP+ / QSFP28 |
| Performance | Routing/switching capacity: 1.2 Tbps ¦ Switch fabric speed: 1.2 Tbps ¦ Switching capacity: 4.8 Tbps ¦ Throughput: 2.678 Mpps |
| Capacity | MAC addresses: 212992 ¦ IPv4 host table capacity: 145780 ¦ IPv6 host table capacity: 145780 ¦ IPv4 routes (Unicast): 606977 ¦ IPv6 routes (Unicast): 630784 ¦ IPv4 ACL entries (ingress): 65536 ¦ IPv6 ACL entries (ingress): 16384 ¦ MAC ACL entries (ingress): 65536 ¦ IPv4 ACL entries (egress): 8192 ¦ IPv6 ACL entries (egress): 2048 ¦ MAC ACL entries (egress): 8192 ¦ VLANs supported: 4094 ¦ IGMP groups: 7000 ¦ MLD groups: 7000 ¦ IPv4 routes (Multicast): 7000 ¦ IPv6 routes (Multicast): 7000 |
| Jumbo Frame Support | 9KB |
| Routing Protocol | OSPF, BGP-4, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, MSDP, static IPv4 routing, static IPv6 routing, ECMP, policy-based routing (PBR), RIPng, MLDv2, MLD, MPLS, CIDR, BGP-MP |
| Remote Management Protocol | SNMP 1, RMON, SNMP 3, SNMP 2c, TFTP, SSH, SSH-2, SSH 6, SFTP, ICMP |
| Features | Flow control, DHCP support, BOOTP support, ARP support, load balancing, VLAN support, IGMP snooping, Syslog support, port mirroring, IPv6 support, High Availability, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), DHCP server, MLD snooping, Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), Deficit Weighted Round Robin (DWRR), DHCP relay, Data Center Bridging (DCB), SNMP trap, dual firmware images, Neighbor Discovery Protocol (NDP), packet storm protection, Strict Priority (SP), Loopback, Ethernet Ring Protection Switching (ERPS), MACsec support, hot swappable 5 fans, Explicit Congestion Notification (ECN), Bridge protocol data unit (BPDU), ICMP Router Discovery Protocol (IRDP), 32MB packet buffer, Virtual Extensible LAN (VXLAN), Link Aggregation, RDMA over Converged Ethernet (RoCE) v2, Ethernet Virtual Private Network (EVPN), fast leave, Network Timing Protocol (NTP), Private VLAN, Cisco IOS IP Service-Level Agreements (IPSLA), IP forwarding support, IPv4 and IPv6 dual stack, DDoS Protection, IPv6 addressing, Virtual Switch Extension (VSX), Aruba Virtual Switching Framework (VSF), Rapid PVST+ (RPVST+), DNS support, UDP support, TCP support, Border Gateway Protocol (BGP), Unidirectional Link Detection (UDLD), IPv6 multicasting |
| Compliant Standards | IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3an, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.3by, IEEE 802.3cc |
| Power | AC 100-240 V |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 17.4 in x 22 in x 1.7 in |
| Weight | 17 lbs |
| Localization | English / United States |
| Manufacturer Warranty | Limited lifetime warranty |
- Aruba CX 8360-16Y2C V2 Switch L3 managed 16 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 2 x 40/100 Gigabit QSFP+ / QSFP28 Front to Back Airflow Rack Mountable AC
MPN: JL703C
