Description
Juniper Networks QFX5220-32CD-AFO 1U System Ethernet Switch
- Cloud providers and network operators are increasingly deploying scale-out, spine-and-leaf IP fabric architectures built on fixed-configuration switches to support growing east-west traffic in the data center.
- The QFX5220 Switch is optimally suited for these high-speed, high-density, spine-and-leaf IP fabrics. Supporting 400GbE, 200GbE*, 100GbE, 50GbE, 40GbE, 25GbE, and 10GbE connections and offering an advanced L2, L3, and MPLS feature set, the QFX5220 enables cloud service providers and network operators to build large, next-generation IP fabrics that support network virtualization and intelligent traffic forwarding based on proven, Internet-scale technology.
- Rich automation capabilities: The QFX5220 switches support a number of network automation features for plug-and-play operations, including zero-touch provisioning (ZTP), operations and event scripts, automatic rollback, and Python scripting.
- Advanced Junos Evolved features: The QFX5220 switch supports features such as BGP add-path, MPLS, L3 VPN, RoCEv2, and Multicast capabilities.
- Junos Evolved software architecture: The QFX5220 supports a modular Junos Evolved software architecture that allows the switch’s control and data plane processes and functions to run in parallel, maximizing utilization of the high-performance quad-core CPU, support for seamless component upgrade without bringing the switch down, and support for containerization, enabling application deployment using LXC or Docker.
Specifications:
- MPN: QFX-5220-32CD-AFO
- Brand: Juniper Networks
- Product Line: Juniper Networks
- Rack Mountable: yes
- Speed: 400 Gigabit Ethernet
- Form Factor: 1U
- Brand: Juniper Networks
- Product Line: Juniper Networks QFX Series
- Model: QFX5220-32CD
- Package Quantity: 1
Chassis:
- Airflow Direction: Back to front airflow
Processor:
- Type: XEON
- Processor Number: D1518
- Installed Quantity: 1
- Manufacture: Intel
Performance:
- Performance: Forwarding capacity: 80000000 packets per second, Switching throughput: up to 12.8 Tbps
Capacity:
- Capacity:
- ARP entries: 32000, Firewall egress filters (VACL, PACL rules): 512, Firewall egress filters RACL rules: 2558,
- Firewall ingress filters (RACL, VACL, PACL rules): 768, GRE tunnels: 2000, IPv4 routes (Unicast): 3800000, IPv6 routes (Unicast): 130000,
- LAG groups: 128, Maximum member ports per LAG: 64, MPLS labels: 16000, Packet buffer size: 128 MB, VLAN IDs: 3968
Networks:
- Type: Switch
- Subcategory: Network hubs and switches
- Subtype: 400 Gigabit Ethernet
- Advanced Switching: Layer 3
- Routing Protocol: IGMP, IGMPv2, MLD, MLDv2, OSPF, OSPFv2, OSPFv3
- Mac Address Table Size: 8192 entries
- Jumbo Frame Support: 9216 bytes
- Manageable: Yes
- Remote Management: SNMP1, SNMP2, SNMP3
- Protocol
- Features:
- Access Control List (ACL) support, ARP support, Bidirectional Forwarding Detection (BFD), BPDU Guard, Bridge protocol data unit (BPDU), Data Center Bridging (DCB), Denial of Service (DoS) protection, DHCP relay, DHCP snooping, Encapsulated Remote SPAN (ERSPAN), Filter-based forwarding (FBF), Firewall protection, High Availability, IGMP proxy, IGMP querier, IGMP snooping, IPv6 support, Loop prevention, Loop-free alternate (LFA), Low-latency queuing (LLQ), MAC address filtering, Management Information Base (MIB), MLD snooping, MPLS support, MPLS VPN, Multicast Source Discovery Protocol (MSDP), Multichassis link aggregation (MC-LAG), Multiple Spanning Tree Protocol (MSTP) support, Port-based VLAN, Priority-Based Flow Control (PFC), Q-in-Q tunneling, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Redundant hot swappable fans, Redundant trunk group (RTG), Remote Switch Port Analyzer (RSPAN), Root Guard, Routed VLAN Interface (RVI), sFlow v5, Smoothed Deficit Weighted Round Robin (SDWRR), Spanning Tree Protocol (STP) support, Storm Control, Switched Port Analyzer (SPAN), Uplink Failure Detection (UFD), Virtual Route Redundancy Protocol (VRRP) support, VLAN Spanning Tree Protocol (VSTP), VLAN support, VLAN trunking, VPN support, Weighted Random Early Detection (WRED), Zero-touch provisioning (ZTP)
- Compliant:
- IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad (LACP), IEEE 802.3x
- Ports: 32 400 Gigabit QSFP56 DD
- Ports 2nd: Quantity 2 / Type 10GBb Ethernet SFP+
Interface Provided:
- Interfaces:
- 1 x console RJ-45, 1 x Gigabit LAN RJ-45 management, 1 x USB Type A, 2 x 10Gbit LAN SFP+, 32 x 400Gbit LAN QSFP56-DD
Software:
- Sofware: Juno
Power Device:
- Type: Internal Power Supply
- Hot Plug: Hot-Plug
- Power Redundancy: Yes
- Power Redundancy: 1+1
- Installed Qty: 2
- Max Supported Qty: 2
- Power Provided: 1600 watt
- Nominal Voltage: AC 120/230 V
- Frequency Required: 50/60 hertz
- Power Consumption:
- Operational: 958 watts
- 80 PLUS Certification: 80 PLUS Silver
Miscellaneous:
- Color: Gray
- Authentication Method:
- RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+
Dimensions and Weight:
- Dimensions and Weight
-
Width 17.2 inchDepth 21.1 inchHeight 1.7 inchWeight 24.49 lbs
-
Service and Support:
- Type: 1-year limited warranty
Environmental Parameters:
-
Min Operating Temperature: 32-degree FahrenheitMax Operating Temperature 104-degree FahrenheitMin Storage Temperature -40-degree FahrenheitMax Storage Temperature 158-degree FahrenheitHumidity Range Operating 5 – 90% (non-condensing)Humidity Range Storage 5 – 95% (non-condensing)
MPN: QFX5220-32CD-AFO
