Description
Dell EMC PowerEdge R740xd2 Rack Server – Custom Configured
- Enterprise Content Server:
- A high-capacity content server that has fast response times maximizes uptime. Designed for streaming media and data-intensive workloads.
- Respond effectively to data growth:
- The Dell PowerEdge R740xd2 Rack Server helps you plan for future growth with large internal storage and cost-efficient drive capacities.
- Deliver two-socket compute performance with flash and fast networking options to meet streaming demands.
- Simplify management of large data sets with automated administration and front-serviceable drives.
- The Dell EMC PowerEdge R740xd2 Rack Server lets you keep your data safely on-premises with built-in security, even as you scale capacity.
- Bring Compute closer to storage:
- The R740xd2 addresses increasing capacity and business demands with flexible storage and performance resources in a space-saving design.
- Streamline Management across your data center:
- Reduce the time required to manage mid-to-large scale environments.
- Deliver uptime and data security:
- Fortify server operations with high availability features and a cyber-resilient architecture.
- Easily protect, detect and recover from cyber-attacks with layers of security embedded in every server.
Operating System:
- Canonical Ubuntu LTS
Citrix Hypervisor
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Processor:
- Up to two 2nd Generation Intel Xeon Scalable Processors with up to 22 cores per processor
Memory:
DIMM Speed
- Up to 2666MT/s
Memory Type:
- RDIMM
Memory Module Slots:
- 16 DDR4 RDIMM slots
Supports registered ECC DDR4 DIMMs only
Maximum RAM:
- RDIMM 1TB
Storage:
Front Bays:
- Up to 24 x 3.5” SAS/ SATA (HDD) max 384TB
Up to 16 x 3.5” SAS/SATA (HDD) plus up to 8 x 2.5” SAS/SATA (SSD) - max 317.44TBi
Rear Bays:
- Up to 2 x 3.5” SAS/ SATA (HDD) max 32TB
Up to 2 x 2.5” SAS/SATA (SSD) drives max 15.36TBi
Storage Controllers:
Internal Controllers:
- PERC H730P, H330, HBA330
External Controllers:
- 12 Gbps SAS HBA
Software RAID
- S140
Internal Boot:
- Boot Optimized Storage Subsystem (BOSS)
HWRAID 2 x M.2 SSDs 240GB or 480GB - Internal Dual SD Module
Security:
- Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires OpenManage Enterprise)
TPM 1.2/2.0, TCM 2.0 optional
Management:
Embedded / At-the Server
- iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Console:
- OpenManage Enterprise
OpenManage Power Center
Mobility:
- OpenManage Mobile
Tools:
- Dell RACADM CLI
Dell Repository Manager
Dell System Update
Dell Server Update Utility
Dell Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services
OpenManage Integrations:
- BMC Truesight
Microsoft System Center
RedHat Ansible Modules
VMware vCenter
OpenManage Connections:
- IBM Tivoli Netcool/OMNIbus
IBM Tivoli Network Manager IP Edition
Micro Focus Operations Manager I
Nagios Core
Nagios XI
Power Supplies:
- 750W Platinum
750W 240VDC Platinum
1100W Platinum
1100W 380VDC Platinum
Hot plug power supplies with full redundancy option
Up to 6 hot plugs fans with N +1 redundancy
Ports:
Network Options:
- 2 x 1GbE BaseT LOM
2 x 1Gb BaseT
2 x 10GbE SFP+
2 x 10GbE BaseT
2 x 25GbE SFP+
2 x 16Gb Fibre Channel
Front Ports:
- 1 x Dedicated iDRAC direct-micro-USB
1 x USB 2.0
Rear Ports:
- 1 x Serial
1 x USB 3.0
1 x VGA
1 x Dedicated iDRAC
Internal Ports:
- 1 x USB 3.0
Slots:
PCIe:
- Up to 5 x PCIe slots (3 x16 + 2 x4)
Video Card:
- 1 x VGA
Bezel:
- Optional security bezel
Form Factor:
- 2U rack server
Dimensions & Weight:
Height:
- 3.4 inches (86.8 mm)
Width:
- 17.6 inches (4448.0 mm)
Depth:
- 31.9 inches (810 mm)
Weight:
- 88.2 lbs (40.0 kg)
Rack Support:
- ReadyRails sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
MPN: Dell EMC PowerEdge R740xd2 Rack Server
